Aston LED
A modern, linear, surface or suspended LED luminaire providing direct or direct and indirect illumination. Designed for individual or continuous mounting, the Aston LED is ideal for a wide range of environments.
Features
– Modern design
– Individual or continuous mounting
– Average rated LED life: >60,000hrs (L80/B10)
– Optimum colour consistency – 3 step MacAdam chromaticity tolerance
IP20 | LED | CLASS I | CE
A modern, linear, surface or suspended LED luminaire providing direct or direct and indirect illumination. Designed for individual or continuous mounting, the Aston LED is ideal for a wide range of environments.
Features
– Modern design
– Individual or continuous mounting
– Average rated LED life: >60,000hrs (L80/B10)
– Optimum colour consistency – 3 step MacAdam chromaticity tolerance
IP20 | LED | CLASS I | CE
A modern, linear, surface or suspended LED luminaire providing direct or direct and indirect illumination. Designed for individual or continuous mounting, the Aston LED is ideal for a wide range of environments.
Features
– Modern design
– Individual or continuous mounting
– Average rated LED life: >60,000hrs (L80/B10)
– Optimum colour consistency – 3 step MacAdam chromaticity tolerance
IP20 | LED | CLASS I | CE
| Technical Information |
|---|
Performance
Light source: LED
Emission: Direct/ Direct-indirect
Luminaire output: 3510 – 7023lm (Dir)/ 5288 – 9950lm (D-In)
CRI: > 80
Material
Body: Sheet steel
Finish: Grey/ White
Diffuser: Opal PMMA
Mounting: Surface / Suspension
Options
3hr emergency
3000K
Microprism diffuser
Infill sections
Internal fuse and LS0H cable
| Product Codes |
|---|
| LAMP | COLOUR TEMP | DIRECT LUMENS | INDIRECT LUMENS | STANDARD GREY | STANDARD WHITE | DALI GREY | DALI WHITE |
|---|---|---|---|---|---|---|---|
| 32W | 4000K | 3510lm | N/A | 62316601 | 62318401 | 62316603 | 62318403 |
| 36W | 4000K | 4149lm | N/A | 62316801 | 62318601 | 62316803 | 62318603 |
| 62W | 4000K | 7023lm | N/A | 62317001 | 62318801 | 62317003 | 62318803 |
| 50W | 4000K | 3305lm | 1983lm | 62317201 | 62319001 | 62317203 | 62319003 |
| 54W | 4000K | 3880lm | 1935lm | 62317401 | 62319201 | 62317403 | 62319203 |
| 80W | 4000K | 6562lm | 1976lm | 62317601 | 62319401 | 62317603 | 62319403 |
| 62W | 4000K | 3330lm | 3209lm | 62317801 | 62319601 | 62317803 | 62319603 |
| 68W | 4000K | 3880lm | 3300lm | 62318001 | 62319801 | 62318003 | 62319803 |
| 93W | 4000K | 6714lm | 3236lm | 62318201 | 62320001 | 62318203 | 62320003 |
