Ikon LED
A robust IP66 surface mounted LED luminaire with excellent technical parameters. It is also available with a microwave sensor for enhanced energy savings.
Features
– Robust design with captive screws
– No spotting – even light distribution
– Long rated LED life: >51,000hrs (L90/B10)
– Optimum colour consistency – 3 step MacAdam chromaticity tolerance
– UV stabilised – no yellowing
IP66 | IK10 | LED | CLASS I | CE
A robust IP66 surface mounted LED luminaire with excellent technical parameters. It is also available with a microwave sensor for enhanced energy savings.
Features
– Robust design with captive screws
– No spotting – even light distribution
– Long rated LED life: >51,000hrs (L90/B10)
– Optimum colour consistency – 3 step MacAdam chromaticity tolerance
– UV stabilised – no yellowing
IP66 | IK10 | LED | CLASS I | CE
A robust IP66 surface mounted LED luminaire with excellent technical parameters. It is also available with a microwave sensor for enhanced energy savings.
Features
– Robust design with captive screws
– No spotting – even light distribution
– Long rated LED life: >51,000hrs (L90/B10)
– Optimum colour consistency – 3 step MacAdam chromaticity tolerance
– UV stabilised – no yellowing
IP66 | IK10 | LED | CLASS I | CE
| Technical Information |
|---|
Performance
Light source: LED
LED output: 2540 – 3710lm
Luminaire output: 2110 – 3130lm
Luminaire efficiency: ≥123lm/W
CRI: >80
Material
Body: Polycarbonate
Finish: White
Diffuser: Opal polycarbonate
Mounting: Surface
Options
Microwave sensor for enhanced energy savings
Grey body
Bluetooth enabled
Internal fuse and LS0H cable
| Product Codes |
|---|
| LAMP | COLOUR TEMP | DELIVERED LUMENS | FINISH | STANDARD | DALI | EMERGENCY STANDARD | EMERGENCY DALI |
|---|---|---|---|---|---|---|---|
| 17W | 3000K | 2110lm | White | 41000501 | N/A | 41000591 | N/A |
| 17W | 4000K | 2140lm | White | 41000601 | N/A | 41000691 | N/A |
| 25W | 3000K | 3070lm | White | 41000701 | 41000703 | 41000791 | 41000793 |
| 25W | 4000K | 3130lm | White | 41000801 | 41000803 | 41000891 | 41000893 |
