Taurus Duo Therm LED
An acoustic and fire rated downlight featuring innovative duo-therm technology, which combines a ceramic and aluminium heat sink for improved thermal management. The combination of Al2O3, offering high electrical insulation (1×1014 – 1×1015) Ω cm, reduces the operating temperature of the lamp by around 8°C which increases life expectancy by approximately 30%. The Taurus Duo Therm LED can be fixed or adjustable and also IP rated. Available with or without a dimmable GU10 LED lamp.
Features
– Available with and without LED lamp
– Slim attractive matt white bezel
– Fire-rated up to 30, 60, 90 minutes
– Twist & lock design
– Average 30,000hrs LED life
– Part B acoustic rated
– Compatible with leading or trailing edge dimmers
– Ideal for low ceiling voids
IP20 | IP65 | LED | CLASS III | CE
An acoustic and fire rated downlight featuring innovative duo-therm technology, which combines a ceramic and aluminium heat sink for improved thermal management. The combination of Al2O3, offering high electrical insulation (1×1014 – 1×1015) Ω cm, reduces the operating temperature of the lamp by around 8°C which increases life expectancy by approximately 30%. The Taurus Duo Therm LED can be fixed or adjustable and also IP rated. Available with or without a dimmable GU10 LED lamp.
Features
– Available with and without LED lamp
– Slim attractive matt white bezel
– Fire-rated up to 30, 60, 90 minutes
– Twist & lock design
– Average 30,000hrs LED life
– Part B acoustic rated
– Compatible with leading or trailing edge dimmers
– Ideal for low ceiling voids
IP20 | IP65 | LED | CLASS III | CE
An acoustic and fire rated downlight featuring innovative duo-therm technology, which combines a ceramic and aluminium heat sink for improved thermal management. The combination of Al2O3, offering high electrical insulation (1×1014 – 1×1015) Ω cm, reduces the operating temperature of the lamp by around 8°C which increases life expectancy by approximately 30%. The Taurus Duo Therm LED can be fixed or adjustable and also IP rated. Available with or without a dimmable GU10 LED lamp.
Features
– Available with and without LED lamp
– Slim attractive matt white bezel
– Fire-rated up to 30, 60, 90 minutes
– Twist & lock design
– Average 30,000hrs LED life
– Part B acoustic rated
– Compatible with leading or trailing edge dimmers
– Ideal for low ceiling voids
IP20 | IP65 | LED | CLASS III | CE
| Technical Information |
|---|
Performance
Light source: LED
Luminaire output: 620 – 840lm
Luminous efficiency: 88lm/W
CRI: 80
Beam angle: 36°
Material
Mounting: Recessed
Options
Lower output lamp
Brushed nickel bezel
Non-dimmable lamp
| Product Codes |
|---|
| LAMP | COLOUR TEMP | LUMENS | FIXED | ADJUSTABLE | IP RATED |
|---|---|---|---|---|---|
| No lamp | N/A | N/A | 30502700 | 30502800 | 30502900 |
| 7W dimmable | 3000K | 620lm | 30503007 | 30503107 | 30503207 |
| 7W dimmable | 4000K | 640lm | 30503307 | 30503407 | 30503507 |
| 7W dimmable | 3000K | 820lm | 30503607 | 30503707 | 30503807 |
| 7W dimmable | 4000K | 840lm | 30503907 | 30504007 | 30504107 |
